POWERHEAD
90-855347R1 JANUARY 1999 Page 4A-37
2. Reinstall retaining ring using a suitable pair of Snap Ring Pliers.
51854
51852
a
b
c
d
e
a-Crankshaft
b-Crankshaft Ball Bearing
c-Suitable Mandrel
d-Press
e-Retaining Ring

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury Optimax 150 and is the answer not in the manual?

Mercury Optimax 150 Specifications

General IconGeneral
Horsepower150 HP
Engine TypeV6
Alternator Output60 amp / 756 watt
StartingElectric
SteeringRemote
Displacement2.5 L
Fuel Induction System2-Stage Direct Fuel Injection (DFI)
Shaft Length20", 25"
Dry Weight431 lbs (20 in), 439 lbs (25 in)
