RIGHT HAND NON-RATCHETING
90-855347R1 JANUARY 1999 Page 6A-9
Gear Housing (Prop Shaft)(Standard Rotation)
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GEAR HOUSING (BLACK)(BASIC)
50 1 CAM FOLLOWER
51 1 SHIFT CAM
52 1 ROD
53
1 FORWARD GEAR (1.87:1 – 15/28)(150)
53
1 FORWARD GEAR (2:1 – 14/28)(135)
54 AR SHIM SET
55 1 TAPERED ROLLER BEARING
56 1 CUP
57 1 NEEDLE BEARING
58 1 CLUTCH
59 1 CROSS PIN
60 1 DETENT PIN
61 1 SPRING
62 1 PROPELLER SHAFT
63
1 REVERSE GEAR (1.87:1 – 15/28)(150)
63
1 REVERSE GEAR (2:1 – 14/28)(135)
64 1 THRUST SPACER
65 1 THRUST RING
66
1
BALL BEARING
67 1 O-RING
68 1 BEARING CARRIER ASSEMBLY
69 1 ROLLER BEARING
70 1 OIL SEAL (INSIDE)
71 1 OIL SEAL (OUTSIDE)
72 1 KEY
73 1 TAB WASHER
74 1 COVER 210 285
75 1 TRIM TAB
76 1 SCREW (1-3/4 IN.) 25 34
77 1 SCREW (3/8-16 x 1 IN.) 30 41
78
2
WASHER
79 2 NUT 50 68

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
