LEFT HAND NON-RATCHETING
Page 6B-4 90-855347R1 JANUARY 1999
18. Bearing Retainer Tool 91-43506
19. Mandrel 91-92788
20. Mandrel 91-15755
21. Dial Indicator Holder 91-89897
22. Bearing Preload Tool 91-14311A1
1
2
3
4
5
6
7
8
1-Adaptor (N.S.S.)
2-Bearing (N.S.S.)
3-Washer (N.S.S.)
4-Spring (24-14111)
5-Bolt (10-12580)
6-Nut (11-13953)
7-Set Screw (10-12575)
8-Sleeve (23-13946)
23. Propeller Shaft 44-93003 and Load Washer (i) 12-37429
24. Forward Gear Installation Tool 91-815850

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
