Merrychef eikon e2 - Loading Oven Programs via USB

Installation and User Manual  Original, GBR
Part Number 32Z3838
Issue 7
23
OPERATION & CONTROLS
J
K
L
M
USB Oven Programs (J)
IMPORTANT: Downloading from a USB will clear
all the existing programs.
Check that the key has the correct number/code
for the programs you want to load into the oven
memory (1 ‘.cbr’ + ‘autoupd.ate’).
With the oven switched o, slide the Merrychef
badge (oven front top right) upwards and insert
the USB Memory Stick into the slot.
Switch the oven ON.
The les automatically download from the USB
showing the progress and conrmation screens for
the update.
On completion the oven displays the start up
screen.
Remove the USB and keep in a safe place.
Reposition the USB cover.
Temperature Band (K)
Select the ‘Temp Band’ symbol at which the oven
controls i.e. ±10°C.
Select the required temperature band checkbox,
shown by a green tick.
NOTE: Although the lowest practical Temp Band
should be used, if the set oven temperature falls by
more than the selected Temp Band, the ready to cook
mode and Temp Band are deactivated until the oven
reaches the preheat temperature.
Change Password (L)
Select the key symbol to change the oven
passwords.
Select the oven settings or service symbol.
Enter the existing password and select OK to
conrm.
Enter the new password, select OK.
Conrm new password, select OK.
Screen Saver (M)
Select the ENABLED checkbox to switch the screen
saver ON or OFF.
Select the time box below to enter a time delay on
the keypad from 1 to 60 minutes before the screen
saver starts and select OK to conrm.
