Software
Operating the Software
8LE-D23_BA_E
20.03.2015
29
/
58
Designation
Description
Trigger
Pulse period for the trigger input based on the selected parameters (Figure 18,
page 33).
LED Light
On / Off duration of the M=Light LED based on the assumed trigger pulse and
selected parameters (Figure 18, page 33)
Delay
Switch-on delay for selected parameters.
Width
Switch-on duration of M=Light LED for selected parameters.
Period
Switch-on / -off cycle of M=Light LED for selected parameters.
