4.3 EB 80 SYSTEM DIAGNOSTIC MODE – VALVE BASE
The diagnosis of bases for valves is defined by the state of the interface Led lights.
The generation of an alarm activates a software electrical connection message with the code associated with the detected error.
Led Green
Base
Meaning FAULT signal output state and storage
OFF The output is not controlled. FAULT signal output – OFF
The output is active and works properly. FAULT signal output – OFF
ON
(double flashing)
Indication for each output.
Solenoid pilot interrupted or missing (dummy valve or valve with
a solenoid pilot installed on a base for two solenoid pilots).
FAULT signal output – Active
The output resets automatically when the cause of failure is removed.
The FAULT signal can only be reset by disconnecting the power supply.
(flashing)
Indication for each solenoid pilot output or base output
short-circuited.
FAULT signal output – Active, permanent
The output is turned off.
It can only be reset by disconnecting the power supply.
(flashing +
simultaneously flashing
of all Led
lights of the base)
Voltage out of range
Less than 10.8V or greater than 31.2V
Caution! Voltage greater than 32VDC irrevocably damages
the system.
FAULT signal output – Active, self-resettable to return within the operating range.
The alerts remain on 5 seconds after resetting.
4.4 EB 80 SYSTEM DIAGNOSTIC MODE – SIGNAL MODULES - S
The diagnosis of Signal Modules - S is defined by the state of the interface Led lights.
The generation of an alarm activates a software electrical connection message with the code associated with the detected error.
4.4.1 Diagnostic mode of Signal Modules - S – Digital Inputs
Led
X1..X8
Meaning Solution
OFF Input not active -
ON (green) Input active -
ON (red) Indication for each input.
Short-circuited or overloaded input.
Remove the cause of the fault
RED
(flashing + all Led
lights flashing
simultaneously)
Overall current input too high. Remove the cause of the fault
4.4.2 Diagnostic mode of Signal Modules - S – Digital Outputs
Led
X1..X8
Meaning Solution
OFF Output not active -
ON (green) The output is active and works properly. -
ON (red) Indication for each output.
Short-circuited or overloaded output.
Remove the cause of the fault
RED
(flashing + all Led
lights flashing
simultaneously)
Overall current input too high. Remove the cause of the fault
