14
OPERATION MANUAL
a. Check that the electrical supply has been connected.
b. Check that the hydraulic tank has been lled with hydraulic oil.
c. Ensure that the emergency stop button is in the released position.
d. Ensure the isolating switch is on and power light is illuminated
e. Press the hydraulic pump button to start the electric motor.
a. Adjust the bend angle adjuster according to your requirements.
b. Ensure the clamp gap has been set according to the thickness of the plate.
c. Once the steel plate is in position for bending then the choice of inching or cycle mode can be
selected.
d. Do not bend material which has been welded or deformed.
5.3 BENDING
5.2 START UP
5.4 CONTROLS
Power Light
Key Switch for
Power To NC89
Switch Le for Manual
Right for Cycle Mode
Emergency Stop
Apron Up
Apron Down
Pump On
Pump O
NC89
Controller
Instructions Manual for PB-460 (S581B)
