4
OPERATION MANUAL
1.1 SPECIFICATIONS
1. GENERAL MACHINE INFORMATION
Machine Type
PB-440A/T PB-825A PB-830A/T PB-860T PB-1030T
Bending Length (mm) 1300 2500 2500 2500 3050
Material Capacity Mild Steel (mm) 4 2.5 4 6 3.2
Stainless Steel (mm) 2 1.2 2 3 1.6
Bending Angle Indicator (deg) 0-120 0-120 0-120 0-125 0-120
Box Depth Of Fingers (mm) 230 215 205 205 205
Opening Height (mm) 140 140 140 140 140
Weight (kgs) 1250 1740 2900 3800 3730
System Pressure (Mpa) 5 5 5 12 5
Pan Movement Speed (mm/sec) 5 5 5 5 5
Clamp Movement Speed (mm.sec) 10 10 10 10 10
Oil Tank Volume (ltr) 60 40 60 60 60
Back Gauge Range (mm) 1000 1000 1000 1000 1000
Main Motor 3Ph 415v 50Hz (KW)
3.75 3.75 5.5 7.5 5.5
1.2. STANDARD EQUIPMENT
q Tools and instruction manual
q Back-gauge assembly
q Side guarding
q Foot switch and control panel
e above specications were current at the time this manual was published, but because of our policy of
continuous improvement, Metalmaster reserves the right to change specications at any time
and without
prior notice, without incurring obligations.
