4.5. Functional description
Afteropeningthetapandswitchingonthedevice,thedosingvalveisopenedand150mlofwaterisaddedtothemixingcontainer.
ThewaterlevelinthemixingcontainerismonitoredbyanelectroniclevelprobeA.Ifthecontactonthisprobeistriggered,magneticvalves2(compressedair)
and1(GREEN&CLEANWK)open.Asaresult,thecompressedair-operateddoublemembranepumpdrawsapprox.1.75mlofhydrogenperoxidefromthe
GREEN&CLEAN WK bottle and adds it to the mixing container.
IfthewaterleveldropsbelowlevelprobeA,thedosingvalveopensagainuntiloverowprobeBisreached.Whenthisprobeisreached,300mlofwaterhasnow
beenaddedtothemixingcontainer.Magneticvalves2and1nowopenagainandaddadditional1.75mlofGREEN&CLEANWKtothemixingcontainer.This
ensures that the required concentration of disinfectant solution is continuously maintained.
Thewaterinletinthemixingtankisdesignedasafreefallsection,whichensuresthattheWEKisseparatedfromthewatersupplynetworkasrequiredbyDVGW
(DIN1988,Part4).AbackowofcontaminatedwaterorwatermixedwithGREEN&CLEANWKtothesupplynetworkisthereforenolongerpossible.
Ifaconsumerisactivated,theconsumptionmediumowsfromthemixingtankviathepressuretanktothecorrespondingconsumers.
Thislowersthewaterlevelinthepressuretankandconsequentlythewaterpressure.Themembranepumpisstartedbymeansofapressureswitchattachedto
thepressuretankandsetto2.5bar.Thismembranepumpisresponsibleforemptyingthemixingtankorllingthepressuretankandformaintainingthenecessary
owpressure.
Anaircushioninthepressuretankcompensatesforthewaterlevel.Ifnecessary,theaircushionisbalancedwithcompressedair(magneticvalve3)-allthisto
ensureastablewaterjetfortheconsumers.Theaircushionprobeensuresthattheairpressureremainsconstant.
ThedisinfectantisdrawnfromtheGREEN&CLEANWKbottle.AdisinfectantsensormonitorsthepresenceofGREEN&CLEANWK.Ifnomoredisinfectantcan
bedelivered(e.g.becausethedisinfectantbottleisempty),anerrormessageisshown.
Please note that only GREEN&CLEAN WK may be used, as the electronic sensor system is matched to it!
Disinfectant concentrate
