Metasys WEK - Construction

Product description | EN
9
9
1
2
3
4
5
6
13
12
10
11
87
Example picture
1 Device description
2 Item number
3 Serial number
4 Connection data
5 Date of manufacture
6 Manufacturer
7 Followinstructionsforuse
8 Protection class II
9 CE mark
10
Nameandaddressoftheauthorizedrepresentative‘sregisteredofcein
Switzerland
11 Separatecollectionofelectrical/electronicequipment(WEEE)
12 Medical device
13
Uniqueidentierofamedicaldevice,
UDImarkingwithstandardcompliantHIBCdatacontent
4.4. Construction
Module 1 Control electronics
24V~
X1
MOT
X2
SIC1
T 1,6 A
X12
200003193v03 | 2024-01
USB MINI-B
X10
METASYS WEK
X11
X3
X5
X18
X23
X24
X25
X22
X16
X13
X6 X4 X7
LED1
LED3
LED2
LED4
BATT
2x LR44
1,5 V
IC3
3
4
2 1
0
87
6
9
Module 2 Pressuretank;thewaterpressureisbuiltupinthistank.Inadditionto
thetank,themodulecontainsamagneticvalve,apressureswitchanda
non-return valve.
Module 3 Membrane pump; contains pump and non-return valve.
