EN | Preparation for use
12
5. Preparation for use
5.1. Transport and storage
Device with cover: Thedeviceisshippedintwopolystyrenetraysfastenedtogetherinacardboardbox.
Built-in version:Thedeviceisshippedinacardboardboxwithbubblewrap.
Thisoriginalpackagingmustbeusedforanyonwardandreturntransport.Thedevicemustalwaysbetransportedandstoredinanuprightposition.Thedevice
must be transported to the installation site in a completely packed state. After unpacking the device, check for completeness and possible transport damage.
Transport and storage temperature 0 °C – 70 °C
Transport and storage humidity limitation max. 80%
5.2. Installation requirements
Operating temperature 10 °C – 40 °C
Humidity limit max. 70%
above sea level ≤3000m
5.2.1. Assembly variants
Installation in the treatment unit
Thedirectintegrationofthewaterdisinfectionsystem intothetreatment unitshouldbe the
preferred solution, as the hose and compressed air routes to the device can be kept as short
as possible.
In the unit, vibration-free suspension of the device on load-bearing parts of the treatment unit
must be ensured.
Installation with cover
If it is not possible to install the device directly in the treatment unit, the set-up can also be
carried out in the optionally available cover.
The cover should be mounted on the connection box of the treatment unit. The external display
and a transformer are already integrated in the cover.
