Page 52 Micro Rain Radar MRR-2 METEK
2012-02-29 Valid for MRR Service Version 6.0.0.3 / Firmware 6.00
8 MRR-2 Specifications
RCPD with Radar module
Operating Frequency:
24.230 GHz
Operating Mode:
FMCW
Modulation:
1.5 - 15 MHz
Output Power:
50 mW (+17 dBm) (antenna foot point)
OoB and Spurious Emission:
< -80 dBm/MHz (antenna foot point)
2
nd
Harmonic:
-37 dBm
ITU-Designation:
30M0N0N
Power Supply:
24 VDC / 1A
Antenna
Type:
parabolic offset antenna
Diameter:
600 mm
3 dB Beamwidth:
approx. 1.5 °
Gain:
40.1 dBi
Junction Box / Power Supply:
Input Voltage:
230 VAC (50 .. 60 Hz)
Output Voltage
24 VAC / 1.5 A
Dimensions:
270 x 170 x 100 mm
Weight:
4 Kg
Antenna Heating (Option)
Power Supply:
230 VAC (50 .. 60 Hz)
Power Output:
approx. 200 W
Complete System:
Weight:
17.5 Kg
Dimensions:
800 x 600 x 850 mm
