METER SATURO - 3.2 COMPONENTS

Control Unit
31.8 cm (12.5 in) x 25.7 cm (10.1 in) x 15.3 cm (6.0 in)
Infiltrometer Head
Total height
18.3 cm (7.2 in)
Inner diameter
17.2 cm (6.75 in)
Insertion ring
Inner diameter
14.4 cm (5.68 in)
Insertion depth
5 cm (1.97 in)
10 cm (3.94 in)
COMPLIANCE
Manufactured under ISO 9001:2015
2004/108/EC and 2011/65/EU
3.2 COMPONENTS
SATURO consists of four main components: the control unit, insertion ring, infiltrometer
head, and water supply tank (Figure10).
Ente
r
BACK
P
O
W
ER
/ ME
NU
Figure10 SATURO components
