MI 3103 GigaOhm Instrument description
6
Legend:
1.......... Display.
2.......... TEST key to start any measurement.
3 ON / OFF key. The instrument is automatically switched off if no action
(changing rotary switch position or pressing any key) is taken for more than 10
minutes.
4.......... Front label.
5.......... Rotary switch to select measurement function.
6.......... CAL key to compensate resistance of the test leads.
2.3 Connectors
Use original test accessories only!
Max. allowed voltage between mains test terminals
and ground is 300 V!
Max. allowed voltage between mains test terminals
is 600 V!
Max. output voltage between test terminals is 1200 V!
Fig. 2. Connectors
