3.2 Instrument messages
Messages are generated on the LCD using special symbols and numeric segment
combinations. The next figure shows all possible display segments and the table under
the figure describes the messages.
Unit
Fig. 4. Display segments
Description of possible display messages:
o.r.
Result is out of range.
CAL
Test leads are compensated.
FUS
Blown fuse (in R
±200mA
and Rcon functions only).
BAT
Message before the instrument is switched off because of
empty batteries
Table 1. Display messages
