Metrix CX 1651

Calibrateur multifonctions CX 1651
Manuel de l'utilisateur 153
Tables of limits
20 V DC Basic range with linearity test
Function Range Value (V) Frequency (Hz) Deviation
allowed(%value)
V-DC 20.0 V 2.0 0.008
V-DC 20.0 V 4.0 0.006
V-DC 20.0 V 6.0 0.005
V-DC 20.0 V 8.0 0.004
V-DC 20.0 V 10.0 0.004
V-DC 20.0 V 12.0 0.004
V-DC 20.0 V 14.0 0.004
V-DC 20.0 V 16.0 0.004
V-DC 20.0 V 18.0 0.004
V-DC 20.0 V 19.0 0.004
V-DC 20.0 V -2.0 0.008
V-DC 20.0 V -4.0 0.006
V-DC 20.0 V -6.0 0.005
V-DC 20.0 V -8.0 0.004
V-DC 20.0 V -10.0 0.004
V-DC 20.0 V -12.0 0.004
V-DC 20.0 V -14.0 0.004
V-DC 20.0 V -16.0 0.004
V-DC 20.0 V -18.0 0.004
V-DC 20.0 V -19.0 0.004
Table I
DC voltage test
Function Range Value (V) Frequency (Hz) Deviation
allowed(%value)
V-DC 2.0 V 1.9 0.004
V-DC 2.0 V -1.9 0.004
V-DC 240.0 V 190.0 0.004
V-DC 240.0 V 240.0 0.003
V-DC 240.0 V -190.0 0.004
V-DC 240.0 V -240.0 0.003
V-DC 1000.0 V 1000.0 0.010
V-DC 1000.0 V -1000.0 0.010
Table II
20 V AC Basic range with linearity test
Function Range Value (V) Frequency (Hz) Deviation
allowed(%value)
V-AC 20.0 V 2.0 1000 0.075
V-AC 20.0 V 4.0 1000 0.050
V-AC 20.0 V 6.0 1000 0.042
V-AC 20.0 V 8.0 1000 0.037
V-AC 20.0 V 10.0 1000 0.035
V-AC 20.0 V 12.0 1000 0.033
V-AC 20.0 V 14.0 1000 0.032
V-AC 20.0 V 16.0 1000 0.031
V-AC 20.0 V 18.0 1000 0.031
V-AC 20.0 V 19.0 1000 0.030
Table III
