Simultaneous functions
The multifunction calibrator allows simultaneous generation of calibrated signal along with measurement of
another signal using the built-in multimeter. To use both parts of the calibrator simultaneously, cable adapters
supplied by the manufacturer are necessary.
When using the calibrator, the following states are possible; each state has its limitation, listed in the table.
Method of use Limitation of output signals Limitation of multimeter’s
function
Method of connection
1 No cable adapter is used. Calibrator’s output signals are not
limited in any way and can be fully
used.
Calibrator’s output signals are
available only at the terminals
located at the front panel.
The multimeter cannot be
used.
If the multimeter is activated,
FAIL error message appears.
2 The calibrator is used with
140-01 cable adapter.
Calibrator’s output signals are not
limited in any way and can be fully
used.
Calibrator’s output signals are
available only at the terminals
located at the cable adapter.
The multimeter can only be
used to measure the external
temperature using a Pt100
sensor built into the adapter.
140-01 cable adapter
connected onto calibrator’s
terminals.
3 The calibrator is used with
140-41 designed for
simultaneous measurement.
OUTPUT 140-41 function is
set to AUX
Calibrator’s output signals are
available only at the terminals
located at the cable adapter; ranges
are limited to:
- DC voltage up to 20 V
- DC current up to 20 mA
- four-wire resistance
measurement.
The multimeter can be used
without limitations and in full
ranges.
SGS sensors can be
connected.
140-41 cable adapter
connected onto calibrator’s
terminals.
OUTPUT 140-41 AUX
4 The calibrator is used with
140-41 designed for
simultaneous measurement.
OUTPUT 140-41 function is
set to PANEL.
Calibrator’s output signals are only
available at the terminals located
at the front panel in full ranges and
can be fully used.
Calibrator’s output signals are not
available at the terminals of the
cable adapter.
The multimeter can be used
without limitations and in full
ranges.
SGS sensors cannot be
connected
140-41 cable adapter
connected onto calibrator’s
terminals.
OUTPUT 140-41 PANEL
5 The calibrator is used with
Option 40 Canon – 2 banana
cable end.
Calibrator’s output signals are not
limited in any way and can be fully
used.
Calibrator’s output signals are only
available on the terminals located
at the front panel.
The multimeter can be used in
the following ranges:
- DC voltage up to 12 V
- DC voltage up to 25 mA
- frequency up to 15 kHz.
Option 40 Cable, connected
onto calibrator’s
AUXILIARY connector.
6 The calibrator is used with
Option 60 Canon – 4 banana
cable end..
Calibrator’s output signals are not
limited in any way and can be fully
used.
Calibrator’s output signals are only
available at the terminals located
at the front panel.
The multimeter can only be
used in the following ranges:
- temperature using TC
sensors
- temperature using RTD
sensors
- resistance up to 2 kOhm
SGS sensors cannot be
connected.
Option 60 cable end ,
connected onto calibrator’s
AUXILIARY connector
7 The calibrator is used with
Option 70 Canon – 4
terminals.
Following output signals can be set
only:
- resistance in four-wire
connection
– resistance temperature sensor
simulation in four-wire connection
Output signals are available on
adapter Option 70 only.
Multimeter cannot be used.
If the multimeter is activated,
FAIL error message appears.
Cable adapter Option 70,
installed on AUXILIARY
connector.
