3.3 Connecting MSB devices
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
16
￭￭￭￭￭￭￭￭
904 Titrando
NOTICE
When connecting MSB devices together, the following must be
observed:
￭ Only one device of the same type can be used at a single MSB con-
nector at one time.
￭ Dosing devices of the 700 Dosino and 685 Dosimat plus type cannot
be connected together with other MSB devices on a shared connec-
tor. These dosing devices must be connected separately.
CAUTION
MSB connections can be extended with the 6.2151.010 cable. The maxi-
mum connection length permitted is 15 m.
3.3.1 Connecting a dosing device
Three dosing devices can be connected to the instrument (MSB 2 to
MSB 4).
The types of dosing devices that are supported are:
￭ 800 Dosino
￭ 700 Dosino
￭ 805 Dosimat
￭ 685 Dosimat plus
Proceed as follows:
1
Connecting a dosing device
￭
￭ Connect the connection cable of the dosing device to one of the
sockets marked with MSB on the rear of the control device.
￭
