10 IMO-R23EN
2. sign Valve Series & Style
Size Range
7150 Standard Bore Class 150
1/2"-2" (DN 15 - 50)
7300 Standard Bore Class 300
1/2"-2" (DN 15 - 50)
730S Standard Bore Class 300
1/2"-2" (DN 15 - 50)
9150 Full Bore Class 150 1/2"-1-1/2" (DN 15 - 40)
9300 Full Bore Class 300 1/2"-1-1/2" (DN 15 - 40)
1. sign Valve Size (Inch / mm)
INCHES 1/2", 3/4", 1", 1-1/2", 2"
DN 15, 20, 25, 40, 50
HOW TO ORDER JAMESBURY 7000/9000 SERIES PLATFORM RAILROAD VALVES
1/2 7150 RR - 31 - 22 36
XTZ 1 A
123 6745 89
3. sign Special Construction
RR Railroad
4. sign End Connection Construction
Size Range
31 Fire Safe Design
All
11 Non Fire Safe Design All
5. sign Body Material
Size Range
22 Carbon Steel (WCB)
All
35 Alloy 20 (CN7M)
Optional in all sizes
36 Stainless Steel (CF8M) All
71 Monel® Optional in all Sizes
Monel is a registered trademark of Special Materials Corp.
Hastelloy is a registered trademark of Haynes International, Inc.
6. sign Ball & Stem Material
Size Range
00** Same as body
All (Carbon steel not available)
36 Stainless Steel (CF8M)
All
71 Monel Optional in all sizes
73 Hastelloy® Optional in all Sizes
7. sign Seat & Seal Material
Size Range
XTZ Xreme
All
TTT PTFE
All
** Use code 00 when trim matches the body material
8. sign Bolts
Nuts Application
1 ASTM A193 Gr B7
ASTM A194 Gr 2H
Carbon Steel
Monel
2
ASTM A193 Gr B8, B8C,
B8M or B8T (Class 2)
ASTM A194 Gr 8B,
8CB, 8MB or 8TB, or
8FB
316 St. Stl.
Alloy 20
4
Monel
Monel All NACE
All Cl2
5 ASTM A193 Gr B7M ASTM A194 Gr 2HM All NACE
9. sign Model
A Model A
To Next Page
