Slurry Pump
WH16AM1TAA0EN_02A.DOC JAN 04-W51
Care and maintenance
6/6
4. Shaft seals for large pumps are also quite heavy. A special shaft extension (E)
facilitates removal and refitting of the seal assembly. The tool is also useful for
removing the bearing assembly.
E
Figure 9.3-4 Shaft extension tool
5. A soft sling (strop) of appropriate lifting capacity (See Approximate Weights Table,
section 11.3) to lift the case assembly is required.
CAUTION
TO PREVENT DAMAGE, ONLY USE A SOFT SLING (STROP) TO LIFT THE CASE.
All of the above special tools can be obtained from Metso Minerals. See section 10.6.
