Metso ND9200H User Manual

20
6.3 Errors 6.4 Warnings
6.5 Notifications
Display message Description
PRESTAGE CUT ERROR Prestage wire is cut or
connector is loose
PRESSURE SENSOR 1
FAILU R E
Actuator pressure sensor
has failed. The device
performance level is
reduced. Change VC circuit
board during next
maintenance activity
PRESSURE SENSOR 2
FAILU R E
Actuator pressure sensor
has failed. The device
performance level is
reduced. Change VC circuit
board during next
maintenance activity
PRESSURE SENSOR 3
FAILU R E
Supply pressure sensor has
failed. Does not affect the
performance level
SPOOL VALVE SENSOR
FAILU R E
Spool valve sensor failed.
Check the sensor
connections. The device
performance level is
reduced. Change VC circuit
board during next
maintenance activity
TEMPERATURE SENSOR
FAILU R E
Temperature measurement
failed. The accuracy of the
measurements is reduced.
Change VC circuit board
during next maintenance
activity
STATISTICS DATABASE
ERROR
Failed to store statistics. The
new measurements will be
lost
EVENT DATABASE ERROR Failed to store events. The
new events will be lost
POSITION CALIBRATION
FAIL ED
Position calibration failed.
Check the configuration
parameters and controller
mounting. Check that the
controller shaft is correctly
aligned.
TUNING FAILED Tuning failed. Check that the
valve is moving properly.
Check the prestage and
spool valve unit.
mA CALIBRATION FAILED mA calibration failed. Check
the mA range
FACTORY SETTINGS
RESTORE FAIL
Failed to restore factory
settings
POSITION SENSOR RANGE
ERROR
Position sensor range failed
during calibration. Check the
configuration parameters
and controller mounting.
Check that the controller
shaft is correctly aligned
CALIBRATION TIMEOUT Calibration timeout occurred
CALIBRATION START
FAIL ED
The calibration starting
conditions are not met.
Check the supply pressure
Display message Description
TOTAL OPERATION TIME
WARNING
Operating time exceeded
limit
VALVE FULL STROKES
WARNING
Valve stroke counter limit
reached
VALVE REVERSALS
WARNING
Valve reversals counter limit
reached
ACTUATOR FULL STROKES
WARNING
Actuator stroke counter limit
reached
ACTUATOR REVERSALS
WARNING
Actuator stroke counter limit
reached
SPOOL FULL STROKES
WARNING
Spool stroke counter limit
reached
SPOOL REVERSALS
WARNING
Spool reversals counter limit
reached
STEADY STATE DEVIATION
WARNING
Warning that steady state
deviation has increased
DYNAMIC STATE DEVIATION
WARNING
Warning that dynamic state
deviation has increased
STICTION LOW WARNING Warning that stiction is
approaching the low limit
STICTION HIGH WARNING Warning that stiction is
approaching the high limit
LOAD FOR OPENING TOO
LOW
Warning that load for
opening is approaching the
low limit
LOAD FOR OPENING TOO
HIGH
Warning that load for
opening is approaching the
high limit
SUPPLY PRESSURE OUT OF
LIMITS
Supply pressure has
exceeded the specified
operating conditions
TEMPERATURE OUT OF
LIMITS
Temperature has exceed the
specified operating
conditions
HUNTING DETECTION
WARNING
Valve hunting detected.
Display message Description
CALIBRATION
SUCCESSFULL
Position calibration
successfully performed
mA CALIBRATION
SUCCESSFULL
mA calibration successfully
performed
TEST CANCELLED Off-line test has been
cancelled
TEST OK Off-line test has been
successfully performed
TEST FAILED Off-line test failed. Repeat
the test sequence
CALIBRATION CANCELLED Calibration has been
cancelled
EXTERNAL RESET Device has booted normally
FACTORY DEFAULTS
ACTIVATED
Factory default database has
been activated by the user
PARAMETERS BACKUP
RESTORED
Parameter backup database
has been activated
PT NOT ACTIVATED (Only with position
transmitter option)
The position transmitter is not
energized
