parameter setting
Pulsar operation parameters can be set in
order to meet your needs.
3 functions can be configured separately:
c output voltage:
Pulsar’s rated output voltage can be
modified using microswitches in the device.
Possible values are 220/230/240V. Pulsar is
set on 230V by default. This setting can only
be changed by qualified technicians.
c energy saving mode:
This function prevents batteries from
discharging if the connected application is
shut down. When the energy saving mode is
activated, Pulsar stops after 5 minutes in
operation on battery. The function is
deactivated by default.
c total discharge protection:
This function prevents damage to the battery
in the event of lengthy discharging linked to
very small power consumption.
When the total discharge protection mode is
activated, Pulsar stops after 90 minutes in
operation on battery.
The function is activated by default.
energy saving total discharge protection
standard PC activated activated
new PC with deactivated deactivated
ACPI function (1)
RNIS modems/telephone deactivated deactivated
(1) Advanced Configuration and PowerInterface, as from end of 1997.
c parameter setting tips:
We recommend the following programmings
according to the application protected by
Pulsar:
