Maximum total power derating is 50%, i.e. 5W unmodulated carrier at 13.8V DC supply.
Transmitter low power option
For applications not requiring nominal TX power it is possible to select to reduce carrier power
by 50% (5W unmodulated carrier).
This reduces electrical power consumption during TX by approximately 40%. This option may
also be helpful in compromised installations to reduce RF feedback issues during TX.
Environmental qualification matrix
The environmental qualification is based on the document DO-160G
Temperature and
Altitude
4.0 Equipment Categories B2, C1
Low temperature
ground survival
4.5.1 -50°C
Low temperature
shorttime operating
4.5.1 -30°C
Low temperature
operating
4.5.2 -20°C
High temperature
operating
4.5.4 +55°C
High temperature
shorttime operating
4.5.3 +65°C
High temperature
ground survival
4.5.3 +85°C
Loss of Cooling 4.5.5 Cooling air not required Convection cooling or
forced air cooling
recommended in
compromised
installations.
Altitude 4.6.1 55,000 feet
Decompression 4.6.2 8,000 to 55,000 feet in 15 seconds
Over pressure 4.6.3 -15,000 feet
Temperature Variation 5.0 Equipment Category B
Humidity 6.0 Equipment Category A
