MICRO-EPSILON induSENSOR EDS Series User Manual

Page 10
induSENSOR, EDS
2.3 Technical Data
Model
EDS
-75
EDS
-100
EDS
-160
EDS
-200
EDS
-220
EDS
-250
EDS
-260
EDS
-300
EDS
-370
EDS
-400
EDS
-500
EDS
-630
Connections S S, F S, F S, F Z S, F Z S, F, Z Z S, F, Z S S, F
Measuring range mm 75 100 160 200 220 250 260 300 370 400 500 630
Linearity ±0.3 % FSO mm 0.23 0.3 0.48 0.6 0.66 0.75 0.78 0.9 1.1 1.2 1.5 1.89
Resolution 0.05 % FSO mm 0.038 0.05 0.08 0.1 0.11 0.125 0.13 0,15 0.18 0.2 0.25 0.315
Repeatability 0.05 % FSO
Temperature range -40 °C ... +85 °C
Temperature stability ±200 ppm / °C
Frequency response -3
dB 150 Hz, optional up to 300 Hz
Output signal 4 - 20 mA
Output load ≤500Ohm
Power supply 18 - 30 VDC
Current consumption max.
40 mA
Connector
Model S 7-pin connector (sensor cable as an option), options radial or axial output
Model F 5-pin radial bayonet-connector with mating plug
Model Z Wire axial
Pressure resistance 450*10
5
Pa max. (Sensor rod, flange)
1
Protection class Sensor rod: IP 69K, elektronics: IP 67
2
Shock
3
IEC 68-2-29
IEC 68-2-27
40 g, 3000 shocks per axis
100 g radial, 300 g axial
Vibration EC 68-2-6
5 Hz ... 44 Hz ±2.5 mm
44 Hz ... 500 Hz ±23 g
