Page 13
induSENSOR, EDS
4. Installation and Assembly
4.1 Precautionary Measures
The measuring tube must not contact the sensor rod during operation.
> Damage to or destruction of the sensor through abrasion is possible.
Do not deform or shorten the measuring tube.
> Loss of specified technical data.
Do not crush the O-ring or damage through sharp-edged items.
> Loss of functionality
4.2 Measuring Tube Guide and Fastening
Mount the measuring tube in the piston bore hold.
The dimensions for the measuring tube are shown, see Fig. 8 et seq. When the piston is moved in the measu-
ring tube must not touch the sensor shaft. Observe the measuring tube position at the zero point
(= 4 mA output), see Fig. 2 et seq. A slightly eccentric mounting of the measuring tube has no negative influ-
ence on the sensor signal.
Mount the measuring tube in the piston by means of pressing or glueing.
Spot clamping is not permissible.
i
The specified technical data are valid only if the measuring tube is used supplied by
MICRO-EPSILON!
