Page 21
induSENSOR, EDS
ø80.0 (ø3.15)
12.0 (.47)
ø55.0 (ø2.17)
30.0 °
1.0 (.04)
3.95
-0.05
(.16
-0.002
)
8.0
(.32)
a
b
c
d
a ø6.2 (ø.24)
b ø34.0
+0.05
(ø1.34
+0.002
)
c ø31.0
+0.1
(ø1.22
+0.004
)
d ø16.0 (ø.63)
Fig. 12 Mounting ring, model EDS- ... -S, dimensions in mm (inches), not to scale
