MICRO-EPSILON induSENSOR EDS Series User Manual

Page 28
induSENSOR, EDS
_
+
_
18...30 VDC
2
3
4
1
U
B
A
+
R
L
I
OUT
EDS-...-S
R
L
can be inserted as an option for adap-
tation of the power loss to high ambient
temperatures, see Chap. 4.4.4.
Fig. 20 Signal monitoring with amperemeter
2
3
4
1
B
V
18...30 VDC
+
+
_
U
OUT
U
_
R
L
I
S
EDS-...-S
If the signal is monitored with a voltmeter
the load resistor R
L
is sized to give the de-
sired output voltage U
OUT
.
Formula: U
OUT
= R
L
* I
Signal
Fig. 21 Signal monitoring with load resistor
and voltmeter
