MT-3000 System Diagram
ORANGE
BLUE
12 VDC
CHASSIS
GROUND
BLUE
CHASSIS
GROUND
LEFT
RIGHT
BLACK
WHITE
RED
BLACK
RED
SERVO
VALVE
TEE “B”
THROTTLE
VALVE
TEE “A”
AGITATION
SHUT-OFF
VALVE
TANK
SHUT-OFF
VALVE
TEE “C”
BLUE
RUN/HOLD
SENSOR
(OPTIONAL)
REMOVE
YELLOW*
TIE
YELLOW*
REVERSED
CONNECTION
ORANGE
BROWN
2 FT. (.6M)
12 FT. (3.6M)
12 FT. (3.6M)
12 FT.
(3.6M)
GREEN*
BLACK*
12 FT. (3.6M)
20 FT.
(6.1M)
MT-3000
CONSOLE
*CABLE TIE COLORS USED TO IDENTIFY CABLES
**
**ORANGE WIRE USED FOR OPTIONAL BOOST SOLENOID TAPE BACK IF NOT USED
