Table 5-22. QSPI Flash Connections
SAM E54
pin
Function QSPI Flash function Shared functionality
PA08 QIO0 Slave In/IO0 -
PA09 QIO1 Slave Out/IO1 -
PA10 QIO2 Write Protect/IO2 -
PA11 QIO3 Hold/IO3 -
PB10 QSCK Clock -
PB11 QCS Chip Select -
5.3.11 I
2
S Signals
The ATSAME54P20A has a built in two channel Inter-IC Sound Controller (I
2
S).
There is no on-board IC connected to this module, but the signals are available on the different pin-
headers on the kit as shown in the table below.
Table 5-23. I
2
S Signals on SAM E54 Xplained Pro
Microcontroller Pin I
2
S Signal Pin-Header Location On-board Shared
PB16 SCK0 EXT2 pin 14
PB17 MCK0 EXT2 pin 13
PA20 FS0 Camera pin 12
1)
SDCARD MCCDA
PA21 SDO Camera pin 11
1)
SDCARD MCCK
PA22 SDI EXT1 pin 11 / Camera
pin 10
1)
PA23 FS1 EXT1 pin 12 / Camera
pin 9
1)
PB28 SCK1 EXT1 pin 15
PB29 MCK1 EXT1 pin 17
Info:
1) Soldering is required to connect these pins to the camera connector. The resistor footprint
R205, R206, R207, and R208 have to be populated by 0-ohm resistors. The location of the
footprints can be found in the Kit Modifications chapter.
Info: The I
2
S module can use more pins than listed in the table above. These signals are not
listed in the table as they are shared with the on-board QSPI Flash and CAN transceiver.
Related Links
Kit Modifications
SAM E54 Xplained Pro
© 2017 Microchip Technology Inc.
DS70005321A-page 29
