2.2 Kit Overview
The SAM E54 Xplained Pro evaluation kit is a hardware platform to evaluate the ATSAME54P20A.
The kit offers a set of features that enables the ATSAME54P20A user to get started with the SAM E54
peripherals right away and to get an understanding of how to integrate the device in their own design.
Figure 2-1. SAM E54 Xplained Pro Evaluation Kit Overview
DEBUG USB
POWER HEADER
EXTENSION 1 HEADER
EXTENSION 2 HEADER
EXTENSION 3 HEADER
SAME5P20A
RESET BUTTON
CURRENT MEASUREMENT
HEADER
SW0 USER BUTTON
USER LED0
32kHz CRYSTAL
BACKUP SELECT
TARGET USB
BACKUP SUPER
CAPACITOR
QTOUCH BUTTON
MCU CURRENT
MEASUREMENT
SELECT JUMPER
I/O CURRENT
MEASUREMENT
SELECT JUMPER
10-PIN CORTEX DEBUG
CONNECTOR FOR
EXTERNAL DEBUGGER
ATECC508A
CRYPTO DEVICE
ADC/DAC HEADER
AT24MAC402
DEVICE
20-PIN CORTEX DEBUG +
ETM CONNECTOR
32Mbit QSPI FLASH
CAN HEADER
PARALLEL CAPTURE
CONTROLLER HEADER
RJ45 ETHERNET
CONNECTOR
POSITION DECODER
HEADER
SDCARD CONNECTOR
(BOTTOM)
12MHz CRYSTAL
KSZ8091
ETHERNET PHY
SAM E54 Xplained Pro
© 2017 Microchip Technology Inc.
DS70005321A-page 6
