Figure 7-7. SAM-ICE using an Atmel-ICE Adapter

Important:

If contention with the on-board EDBG occurs, power the Xplained Pro board from another input

like the external power header or from the target USB. Physically removing the connection

between the EDBG and the debug header by removing 0Ω resistors, where available, or cutting

the tracks to the EDBG can also be done.

SAM E54 Xplained Pro

DS70005321A-page 44
