Microlife BP B2 Basic User Manual

4
The higher value is the one that determines the evaluation.
Example: a blood pressure value of 140/80 mmHg or a value of
130/90 mmHg indicates «blood pressure too high».
Appearance of the irregular heartbeat (IHB) symbol
This symbol BT indicates that an irregular heartbeat was detected.
In this case, the measured blood pressure may deviate from your
actual blood pressure values. It is recommended to repeat the
measurement.
4. Data memory
This device automatically stores the last 30 measurement values.
Viewing the stored values
Press the M-button 3 briefly, when the device is switched off. The
display first shows «M» AP, and «A»which stands for the average
of all stored values.
Pressing the M-button again displays the previous value. Pressing
the M-button repeatedly enables you to move from one stored
value to another.
Clearing all values
If you are sure that you want to permanently remove all stored
values, hold down the M-button (the device must have been
switched off beforehand) until «CL ALL» appears and then
release the button. To permanently clear the memory, press the
time button while «CL ALL» is flashing. Individual values cannot
be cleared.
5. Battery indicator and battery change
Low battery
When the batteries are approximately ¾ empty the battery symbol
AN will flash as soon as the device is switched on (partly filled
battery displayed). Although the device will continue to measure
reliably, you should obtain replacement batteries.
Flat battery - replacement
When the batteries are flat, the battery symbol AN will flash as soon
as the device is switched on (flat battery displayed). You cannot
take any further measurements and must replace the batteries.
1. Open the battery compartment 7 at the back of the device.
2. Replace the batteries – ensure correct polarity as shown by the
symbols in the compartment.
3. To set date and time, follow the procedure described in Section
«1. Using the device for the first time».
Which batteries and which procedure?
Using rechargeable batteries
You can also operate this device using rechargeable batteries.
Information for the doctor in case of repeated appearance of
the IHB symbol:
This device is an oscillometric blood pressure monitor that also
measures the pulse during blood pressure measurement and
indicates when the heart rate is irregular.

Blood pressure readings with suboptimal cuff fit AR-A are
not considered in the average value.

Pay attention that the maximum memory capacity of 30
memories is not exceeded. When the 30 memory is full,
the oldest value is automatically overwritten with the 31
value. Values should be evaluated by a doctor before the
memory capacity is reached – otherwise data will be lost.

Cancel deletion: press ON/OFF button 1 while «CL
ALL» is flashing.

The memory retains all values although date and time must
be reset – the year number therefore flashes automatically
after the batteries are replaced.

Use 4 new, long-life 1.5 V, size AA alkaline batteries.

Do not use batteries beyond their date of expiry.

Remove batteries if the device is not going to be used for a
prolonged period.

Only use «NiMH» type reusable batteries.

Batteries must be removed and recharged when the flat
battery symbol appears. They should not remain inside the
device as they may become damaged (total discharge as a
result of low use of the device, even when switched off).

Always remove the rechargeable batteries if you do not
intend to use the device for a week or more.

Batteries cannot be charged in the blood pressure monitor.
Recharge batteries in an external charger and observe the
information regarding charging, care and durability.

Microlife BP B2 Basic Specifications

General

Type	Automatic
Cuff size	22 - 42 cm
Control type	Buttons
Product color	White
Number of users	1 user(s)
Measuring method	Oscillometric
Memory registers	30
Pulse rate range	40 - 200
Speaking function	No
Placement supported	Upper arm
Units of measurement	mmHg
Mean arterial pressure	Yes
Display type	LCD
Battery type	AA
Battery voltage	1.5 V
Battery technology	Alkaline
Battery life (CIPA standard)	920 shots
Number of batteries supported	4
Quantity per pack	1 pc(s)
Pressure accuracy	1 mmHg
Pressure measurement range	20 - 280 mmHg

Weight and Dimensions

Depth	90 mm
Width	131 mm
Height	60.5 mm
Weight	277 g

Summary

Blood Pressure Monitor Preparation

Body Positioning

Sit on a back-supported chair and keep your legs uncrossed.

Clothing Restrictions

Avoid thick or close-fitting garments on the upper arm.

Arm Artery Alignment

Place the artery-mark on the cuff over your artery.

Cuff Fit Adjustment

Fit the cuff closely, but not too tight.

Cuff Positioning

Position the cuff 1-2 cm above your elbow.

Measurement Stillness

Keep your arm still and do not speak during the measurement.

Pre-Measurement Checklist

Lifestyle and Relaxation

Avoid eating, smoking, caffeine, and relax for 5-10 minutes.

Measurement Timing

Measure before medication intake.

Device Components and Safety

Intended Use of Device

For measuring non-invasive blood pressure in people aged 12 years or older.

General Safety Precautions

Follow instructions, handle with caution, and keep away from children.

Initial Device Setup

Battery Installation

Insert batteries (4x1.5V AA) into the compartment, observing polarity.

Setting Date and Time

Set year, month, day, hour, and minutes using the buttons.

Cuff Size Selection

Choose the appropriate cuff size for your upper arm circumference.

Taking a Blood Pressure Measurement

Pre-Measurement Routine

Avoid activity, relax, sit correctly, keep feet flat, measure on same arm.

Arm and Cuff Placement

Ensure correct cuff fit, position 1-2 cm above elbow, artery alignment.

Measurement Process

Press ON/OFF, relax, and wait for the automated measurement result.

Evaluating Blood Pressure Readings

Understand display symbols and pressure ranges (normal, elevated, high).

Data Memory Management

Viewing Stored Values

Press M-button to cycle through the last 30 measurements.

Clearing Memory

Hold M-button to permanently clear all stored values.

Battery Management

Low Battery Indicator

Replace batteries when the low battery symbol appears.

Battery Types and Care

Use AA alkaline or NiMH rechargeable batteries; remove for long storage.

Using Optional Accessories

Mains Adapter Usage

Connect adapter to device and wall socket; no battery consumed.

Error Message Troubleshooting

Understand error codes (ERR 1-5, HI, LO) and their remedies.

Safety, Care, and Disposal

Contra-Indications for Use

Do not use for pediatric patients or with certain limb conditions.

Device and Limb Precautions

Avoid damage, keep away from children, and protect limbs from pressure.

Maintenance and Guarantee

Cleaning the Cuff

Hand wash cuff cover in soapy water (max 30°C).

Accuracy Testing and Disposal

Test accuracy every 2 years; dispose of batteries/device correctly.

Product Guarantee Information

5-year guarantee for device, 2-year for cuff bladder tightness.
