Micron Scorpion Z4120C User Manual

13
LOCATION
CONTENTS & FIELD SIZE
REMARKS
390
Entry delay zones select (toggle)
Default 1
392
Alternate entry zones select (toggle)
394
Follower entry zones select (toggle)
396
Swinger shutdown zones select (toggle)
Default All zones
398
Cross zones select (toggle)
400
Pre-alert zones select (toggle)
Default 1
402
Chime zones select (toggle)
404
Select outputs to mimic key beeps
Led 1: Siren output
Led 2: Aux. Output 1
Led 3: Aux. Output 2
406
Select output to mimic Arm / Disarm state Area A
Led 1: Siren output
Led 2: Aux. Output 1
Led 3: Aux. Output 2
408
Same as Loc. 406. Area B.
410
Miscellaneous system settings (toggle)
Led 1: Zone led‟s latch while area not armed
Led 2: Quick-arm command enabled
Led 3: 1+3 at power-up into program mode enabled
Led 4: 50/60Hz select. On = 60Hz
Led 5: Answer phone defeat
Led 6: „Follow me‟ mode enabled
Default 2 3 5
412
More miscellaneous system settings (toggle)
Led 1: On = No zone restore reports
Led 2: On = NiteWatch arm in instant mode
Off = NiteWatch arm in delayed mode
Led 3: Auto-arm mode:on=night arm; off=away arm
Led 4: Force arming enable
Led 5: Default dialing ratio, on = 70/30 , off = 60/40
Led 6: Default dial mode, on = pulse, off = DTMF
Default 4
Led 5 only applicable
if led 6 is on.
414
Zones to activate siren output (toggle)
Default All zones
416
Zones to activate aux1 output (toggle)
Default All zones
418
Zones to activate aux2 output (toggle)
Default All zones
420
System events to activate siren output (toggle)
Led 1: NightWatch panic
Led 2: Two key panic
Led 3: Fire panic
Led 4: Siren output fault (use in Loc‟s 422 & 424)
Led 5: Communications failure
Led 6: Line fail
Default 1 2
422
System events to activate Aux1 output (toggle)
Default 1 2
424
System events to activate Aux2 output (toggle)
Default 1 2
426
Output options (toggle)
Led 1: Invert siren output (N/A if led 4 on)
Led 2: Invert Aux1 output
Led 3: Invert Aux2 output
Led 4: Siren output sends wail to a speaker
Led 5: Aux1 set as smoke reset output
Led 6: Aux2 set as smoke reset output
Default 2 3 4
428
User 1 code options (toggle)
Led 1: User code is in area B
Led 2: User is a master user
Led 3: User can arm only
Led 4: User may bypass zones
Led 5: User movements are not reported
Led 6: User code arm/disarm by touchtone phone
Default 2,4,6
430
User 2 code options (toggle)
432
User 3 code options (toggle)
434
User 4 code options (toggle)
436
User 5 code options (toggle)
438
User 6 code options (toggle)
