Micron Scorpion Z4120C User Manual

14
LOCATION
CONTENTS & FIELD SIZE
REMARKS
440
User 7 code options (toggle)
442
User 8 code options (toggle)
444
User 9 code options (toggle)
446
User 10 code options (toggle)
448
User 11 code options (toggle)
450
User 12 code options (toggle)
452
User 13 code options (toggle)
454
User 14 code options (toggle)
456
User 15 code options (toggle)
Disarm all areas Z8020C,
Night-Lock Z6020C, Z4120C
458
User 16 code options (toggle)
460
User 17 code options (toggle)
462
User 18 code options (toggle)
464
User 19 code options (toggle)
466
User 20 code options (toggle)
468
User 21 code options (toggle)
470
User 22 code options (toggle)
472
User 23 code options (toggle)
474
User 24 code options (toggle)
476
Quick arm reporting
Led 5: User movements are not reported
478
Night or instant reporting
Led 5: No report
480
Key switch reporting
Led 5: No report
482
Auto arm reporting
Led 5: No report
Dialing and Reporting
Locations 0 – 63 Phone Number List.
When entering data into the phone number list, the control digit 15 must precede digits representing a protocol
(see following table). All other digits [eg. phone number] may be entered in normal sequence. The panel defaults
to DTMF dialing, therefore it is only necessary to program the DTMF protocol digit [1] if dialing is switching between
Decadic and DTMF part way through dialing. Therefore if the panel is to dial DTMF 3 7 8 6 0 1 4, the number may
be programmed directly starting at Location 0. At the end of each phone number the control digit 15 must be entered
followed by a protocol digit.
To enter a hex digit [11, 12, 13, 14 or 15] press and hold down the ‘Star’ key [tens] and then press the second
digit of the hex number. Example: To enter a 15, press and hold down the „Star‟ key and press 5 at the same time.
A 10 may be programmed as a 0 or a 10.
Phone number digits
DIGIT
MEANING
Clear/Erased
End of call – terminate call
1~9 inclusive
Dial digits 1 through 9
0 (or 10)
Dial 0
11
Dial a * (This is usually a space in a pager message)
12
Dial a # (This is usually „message end‟ pager message)
13
Pause for 3 seconds
14
Initiate call progress
15
Control digit – precedes protocol digit
Protocol digits
DIGIT
PROTOCOL
Clear/Erased
Not allowed – call aborted
1
Switch to DTMF
2
Switch to Decadic 60/40 make break ratio
3
Switch to Decadic 70/30 make break ratio
4
3+2 & 4+2 @ 10bps 2 rounds 1900Hz
5
3+2 & 4+2 @ 20bps 2 rounds 1800Hz
