Zone Options - Programming
Location 364 Cross Zoning [Double Knock]
There are 4 options. Enter 1 digit to select.
Erased: No cross zones
1 2 activations on the same zone
2 2 activations on 2 different zones
3 2 activations on the same zone or 2 different zones
Location 365 Cross Zoning Timer
Enter a value in the range 1 to 15 minutes. If this location is erased the timing is set to 30 seconds. This is the time
that the panel will wait for a second activation after a first activation. If the timer expires with no further activations the
timer is re-set, no alarm is signaled and no report is transmitted.
Location 366 – 373 Zone Filters [Zone Sensitivity]
This is the zone response time. Enter 1 digit to select the sensitivity required for each zone. Response times of less
than 160mS should be reserved only for special sensors [vibration etc.]
Erased 10mS 1 20mS
2 40mS 3 80mS
4 160mS 5 320mS
6 640mS 7 1.28 Seconds
Zone Programming
The zone led‟s are used as selection indicators for this section of programming. Example: To select zone 4 press digit
4, the zone 4 led will light. To de-select zone 4, press digit 4 again. You may toggle zones on and off as required.
Once the selection is complete, press „Enter‟.
Location 374 Area A Zones Select
Select the zones for area A from the keypad. [Zones selected here and in Loc. 376 (area B) become common zones
(Z8020C ONLY)]. Any zone not selected in area A [or B] is disabled and performs no further function.
Location 376 Area B Zones Select [Z8020C Only]
Select the zones for area B. Zones also selected in area A are common zones.
Location 382 Keyswitch Zones Select
Select zone[s] to act as keyswitch arming. Any zone selected here will arm the area in which the same zone is
selected. Example: If zone 4 is programmed as an area A zone in Loc. 374 and also as a keyswitch zone, then
momentarily opening this zone will arm area A.
Location 384 24 Hour Zones Select
Select zones for 24 hour response. Any zone selected here must also be selected in Loc. 374 or 376. If more than
one zone is selected here and they are performing different functions [eg. Fire & Tamper] then it will be necessary to
program the correct reporting codes in Locs. 184-198 [Contact ID] or Locs. 256-270 [non Contact ID]. Select the
correct Contact ID reporting code from the list at Loc. 184. The central station specifies Non Contact ID codes.
Location 386 Night Zones [or] Instant Zones
Select the zones here that will arm in Night or Instant mode.
Location 390 Entry Delay Zones Select
Select zones for entry delay. Zones must also be selected at Locs. 374 or 376. See also Loc. 350 for delay.
Location 392 Alternate Entry Zones Select
Select alternate entry zones. Zones must also be selected at Locs. 374 or 376 and 390. See also Loc. 352 for delay.
Location 394 Follower Zones Select
Select follower zones. These zones will also act as entry zones if a zone selected at Loc. 390 is tripped first. If a
zone selected at Loc. 390 is not tripped first then these zones will alarm without delay.
Location 396 Swinger Shutdown Zones Select
Select zones which will automatically shut down after multiple activations. Select count at Loc. 359.
Location 398 Cross Zones [Double Knock Zones] Select
Select zones for cross activation. Zones selected must also be selected at Locs. 374 or 376. See also Loc. 364.
