2. Configuring the IP-Phone - LCD Menus
Note:
1. After any configuration is made for the IP-Phone , user has to do Reboot in
the selection 7 “Reboot”.
2. We suggest user to set IP address via LCD menu 5→2.3.4.5 first, then go to
chapter 3 to do other detail configurations via web browser.
2.1. Initialize IP-Phone
When power on the IP-Phone, the LCD screen shows as below. Now IP-Phone is running
Boot sector program.
IP-Phone
Board Start Booting
When IP-Phone finishes boot program initialization. User can see flashing greeting as
below:
System Initializing…………..
Then IP-Phone get into standby mode:
IP-Phone
Proxy 10:10:10 AM
The main LCD screen would be shown as similar as above. “Proxy” means the IP-Phone is
in Proxy Mode, and when IP-Phone is connected to SNTP server, on LCD will show current
time captured from SNTP server.
When IP-Phone is under peer-to-peer mode, on LCD will show “P2P” instead of “Proxy”.
IP-Phone
P2P 10:10:10 AM
After pressing the PSTN button, the “Proxy” or “P2P” will be replaced by “PSTN”. Please
