Parameter description:
z Link:
Shows the link status of each port. The column lights green with the link speed
while there is valid connection on this port.
z Mode:
Select a speed for this port. “Auto Speed” enables auto-negotiation. “Disable”
stop the port from functioning.
z Flow Control
There are two modes to choose in flow control, including Enable and Disable. If
flow control is set Enable, both parties can send PAUSE frame to the
transmitting device(s) if the receiving port is too busy to handle. When it is set
Disable, there will be no flow control in the port. It drops the packet if too much to
handle. Default: Enable
z Max Frame length:
To adjust max frame size. The length is 1518 bytes. The Maximum value can be
up to 9600 bytes.
To save the configuration of the system, click “Apply” to save. You can also click
the “Refresh” button to see the latest status of each port.
