Subnet mask is used to set the subnet mask value, which should be the same
value as that of the other devices resided in the same network it attaches.
Default: 255.255.255.0
32 bits
Network ID Host ID
Network ID Host ID
Subnet number
z Gateway:
Set an IP address for a gateway to handle those packets that do not meet the
routing rules predefined in the device. If a packet does not meet the criteria for
other pre-defined path, it must be forwarded to a default router on a default path.
This means any packet with undefined IP address in the routing table will be
sent to this device unconditionally. Default: 192.168.1.254
z Management VLAN:
The VLAN group that is allowed to access the WEB-based management
interface
.
z User name:
The login name. (Default: admin)
z Password:
The login password. (Default: admin)
z System Name:
The name of the device.
To save the configuration of the system, click “Apply” to save
Note: After applying a new IP address, a new login page will be started
automatically. Please login again to proceed to other configurations.
3.3.2 Port
Ports Configuration is applied to change the setting of each port. In this
configuration function, you can set/reset the following parameters, Mode, Flow
Control and Max frame. All of them are described in detail below.
12
