5. Appendix- Command Line Interface
Start-up and Terminal configuration
To start-up the command line interface, please connect a PC COM port to the RS-232
connector and activate a terminal emulation software (e.g. HyperTerminal of Windows.)
The terminal emulation software should be started as the following configuration:
1. Data rate: 115200 baud
2. Data format: 8 data bits, 1 stop bit and no parity
3. Flow control: none.
4. Click the property icon, select settings, make sure that:
5. “The Function, arrow, and ctrl keys act as”: Terminal keys
”Emulation”: VT100
Login/Logout Procedures
To get access to the CLI, you will have to get the username and password for login. The
default username and password are admin/admin.
Note: We recommend users to configure a new username/password to prevent
unauthorized users from accessing to the device.
