D5CUB System Board Manual
Section 4: The BIOS Setup Utility
39
head landing zone (LANDZ), number of sectors per track
(SECTOR), and HDD mode (MODE).
Diskette A or B
To configure a floppy drive added to or removed from
your computer, use <→/←↑/↓> arrow keys to select the
desired drive. Use the <PU/PD/+/-> arrow keys to
change the setting until it matches the floppy drive you
installed. The BIOS supports 2.88MB, 1.44MB, 1.2MB,
720KB and 360KB floppy drives.
Video
This sets the type of video board installed into the system.
The default setting is EGA/VGA.
Halt On
Halt On enables the system to halt on several conditions.
The default setting is All Errors.
Base/Extended/Other Memory
A small section in the lower right corner of the screen
displays important information about your system that
includes the base, extended and other memory sizes.
They are updated automatically by the SETUP program
according to the status detected by the BIOS self-test.
