D5CUB System Board Manual

Section 3: Installing the D5CUB

Memory Bank 0 Bank 1

8MB (2) 1MBx32/36

16MB (2) 1MBx32/36 (2) 1MBx32/36

16MB (2) 2MBx32/36

24MB (2) 2MBx32/36 (2) 1MBx32/36

32MB (2) 4MBx32/36

32MB (2) 2MBx32/36 (2) 2MBx32/36

40MB (2) 4MBx32/36 (2) 1MBx32/36

48MB (2) 4MBx32/36 (2) 2MBx32/36

64MB (2) 8MBx32/36

64MB (2) 4MBx32/36 (2) 4MBx32/36

72MB (2) 8MBx32/36 (2) 1MBx32/36

80MB (2) 8MBx32/36 (2) 2MBx32/36

96MB (2) 8MBx32/36 (2) 4MBx32/36

128MB (2) 8MBx32/36 (2) 8MBx32/36

128MB (2) 16MBx32/36

256MB (2) 16MBx32/36 (2) 16MBx32/36

Memory Configurations

The table below lists the most common memory configu-

rations. The memory available depends on the number

of SIMMs installed.

Table 3-1: Memory Configurations
