D5CUB System Board Manual
Reset Configuration Data
When enabled the system will automatically clear out
the previous PnP and PCI configuration data. The de-
fault setting is Disabled. NOTE: You should enable this
selection whenever you add or remove PnP and PCI add-
on devices.
PCI IRQ Activated By
This selection programs the PCI IRQ to single edge or
logic level. Level/Edge sensitivity is programmed per
controller. Every IRQ input for a given bank is either
Level (default) or Edge triggered.
PCI IDE IRQ Map To
This selection defines the onboard IDE IRQ routing
either from the PCI Bus or the ISA Bus. The default
setting is PCI-AUTO.
Primary/Secondary IDE INT#
These selections defines the primary/secondary IDE
INT# of the PCI IDE card. The default setting for
Primary IDE INT# is A and the default setting for
Secondary IDE INT# is B.
Section 4: The BIOS Setup Utility
47
