Cabling Configurations
System Components
2
MicroHAWK MV-20 / MV-30 / MV-40 Smart Camera Guide 2-17
1
21
22
20
19
22 or 23
Common
(12-Pin Plug
to 12-Pin
Socket)
To Host
(Ethernet
8-Pin Plug
to RJ45)
To Trigger
To Power
Supply
MicroHAWK MV-40 with QX-1 Interface Device
