Configuring the SyncServer
Quick Start Guide
This topic guides the user on how to:
n Configure a SyncServer (see "Configuring the SyncServer" on page 13) that still has
its original factory configuration.
n Read the status LEDs on the front panel.
n Shut the SyncServer down correctly.
This topic is included in the main User Guide. For more information about the features and
tasks described here, consult the following sections in the main User Guide:
n Web Interface (on page 19)
n Keypad/Display Interface (on page 73)
n Specifications (on page 83)
n Tasks (on page 97)
Configuring the SyncServer
Recommended Tasks
GPS antennas not rated for 12 VDC power may be damaged if connected to the SyncServer.
1. Mount the standard L1 GPS antenna (supplied) in a location that offers good visibility of
GPS satellites, such as a rooftop or outdoor antenna mast with wide open views of the
sky and horizon. Avoid obstructions and sources of Radio Frequency Interference.
Observe building codes and regulations. Also see Using GPS (on page 100) and
WARNING: GPS Antenna (see "Safety Considerations" on page 100).
2. On the rear panel:
n
Connect the GPS antenna cable (supplied) to the GPS Ant connector.
n
Connect LAN1 and any of the other network ports to the network.
n Consult Warnings and Cautions for safety information regarding grounding and
power.
n Connect the power and turn the power switch on.
3. Using the front panel keypad:
n
Configure LAN1 with a static IP address using the MENU button and 1) LAN1.
n
View the LAN1 IP address by pressing the STATUS button repeatedly until the
LAN1 STATUS screen is shown.
4.
Go to the SyncServer Login page by entering the LAN1 IP address as the URL in Internet
Explorer.
5. Log in. The user name is "admin". The password is "symmetricom".
6.
Configure the SyncServer using WIZARDS - 1st Setup. Select the following options:
997-01520-02 Rev. G2.......................................................................... Page 13
