TIME Button
Keypad/Display Interface
The keypad/display interface displays the time, system status, and provides the following
functions:
n Configuring and enabling/disabling the LAN1 network port.
n Setting the time and entering freerun mode.
n Adjusting the brightness.
n Locking the keypad.
n Shutting down the SyncServer.
n Backing up and restoring the configuration from the USB port.
n Upgrading the software from the USB port.
Overview
When the SyncServer starts, the display shows the Microsemi logo followed by booting mes-
sages. After a minute or so, the SyncServer displays the default time screen.
The following buttons are user-input devices for the keypad/display interface.
n
ENTER: Use with MENU - Applies a menu selection or function setting.
n
CLR: Use with MENU - Returns to the previous screen without saving changes.
n
Left/Right Arrow Buttons: In functions, moves the cursor left or right. In status, scrolls a
screen horizontally when "<previous:next>" is displayed.
n
Up/Down Arrow Buttons: In functions, increments/decrements the value the cursor is on. In
status, displays the previous/next screen.
n
Number Buttons: Enters a number, or selects a numbered menu item.
The following three buttons change the function of the display.
n
TIME: Changes the format and contents of the time display.
n
STATUS: Displays status the network ports and aspects of the SyncServer.
n
MENU: Displays a menu of functions.
In This Chapter
TIME Button 73
STATUS Button 74
MENU Button 76
TIME Button
Pressing the TIME button repeatedly changes the format and contents of the time display:
n Large numeric time display on full screen. Hours:Minutes:Seconds
n Medium numeric time display on the left, current reference and NTP Stratum on the right
997-01520-02 Rev. G2.......................................................................... Page 73
