Keypad/Display Interface
Note: If you use a GPS antenna splitter, the status can become Open while the GPS receiver
is still able to operate normally.
Lat: The latitude of the SyncServer.
Mode: The acquisition mode of the receiver: Survey (GPS receiver is determining its pos-
ition), Dynamic (a user-configured mode for mobile applications) or Hold (the GPS receiver
has determined its precise location, or the user has manually entered the location).
Lon: The longitude of the SyncServer.
Also see REFERENCES - GPS.
SyncServer Status Screen
Hardware and software identification. Software upgrade availability.
Model: The model number.
S.N.: The serial number.
Version: The software "Release Version" number.
Upgrade Available: Shows "Yes" if the SyncServer detects that more recent version of soft-
ware is available at www.microsemi.com.
Also see SYSTEM - General (on page 52) and SYSTEM - Upgrade (on page 53).
MENU Button
Pressing the MENU button presents a tree-structured menu of functions:
1) LAN1
1) Config
1) IPv4
1) Static Addr (Apply a static IP address)
2) DHCP (Automatically get a dynamic IP address)
2) IPv6 (Automatically configure LAN1 with an IPv6
link local address. IPv6-only mode.)
2) On/Off
1) On (Enable the LAN1 network port)
2) Off (Disable the LAN1 network port - all traffic
types)
2) Brightness (Adjust the brightness of the front panel
display)
1) Low (Extends display life)
2) Medium
3) High
3) Shutdown (Press 1 to halt the SyncServer)
1) Yes
2) No
4) USB (Backs up or restores the configuration to/from a USB
flash drive)
Page 76..........................................................................997-01520-02 Rev. G2
