调高器说明书
Lift stepper motor
Standard high frequency cable
Detector ring anti-collision device
Operating display panel
Cutting torch holder
Detector ring holder
Flame cutting torch
Detector ring
Fig. 3-1 The positions, names and functions of controller components
6 M6 screw holes in the back of the height controller are used to fix t he
box body to the support. Their position and size are shown in Fig. 3-2.
