Microzone 8B-MINI - 02 Introduction to Standard Receivers

DIGITAL PROPORTIONAL R/CSYSTEM
www.microzone.cn
2.4GHz
FHSS
External input power supply
For indoor testing
INTRODUCTION TO STANDARD RECEIVERS
MC9002
(S)signal
(+)positive
electrode
(-)negative
electrode
FM button
After the receiver is powered
on, press the frequency pairing
button and turn on the power
switch of the remote control,
the frequency pairing is
successful
8 PWM signal
External antenna
(-)negative
electrode
1 SBUS signal
-04-
(+)positive
electrode
(S)signal
