Trimmer switch:
The lower left trimming switch corresponds to channel 4, and the right trimming switch corresponds to
channel 1; Upper left fine adjustment switch, left modeCorresponds to channel 3, and the right arrow mode
corresponds to channel 2; Upper right fine adjustment switch, left mode corresponds to channel 2, right
modeEquation corresponds to channel 3; As shown in the following figure.
4 1
3
Left hand mode
2
Right hand mode
2
3
Right hand mode
Left hand mode
