8 Chapter 1: Introduction
VeniceF
Operator Manual
The following table shows the signal flow in detail.
Signal Sourced from Routed to
Mono Balanced XLR mic/line
input or balanced Jack line
Z input (common gain
control with above) or
FireWire connection or
insert return
Buses, insert Jack, direct
output Jack and FireWire
connection
Stereo Balanced XLR mic/line
input and balanced Jack
line Z input (independent
gain control) or FireWire
connection
Buses and FireWire
connection
Stereo return Balanced Jack Buses
Group Bus Master and matrix buses,
insert Jack, group output
balanced XLR and optional
FireWire connection (in
place of stereo input
channel)
Aux Bus Insert Jack, monitor
output balanced XLR and
optional FireWire
connection (in place of
stereo input channel)
Monitor Bus Insert Jack, monitor
output balanced XLR and
optional FireWire
connection (in place of
stereo input channel)
Matrix Insert Jack Insert Jack, matrix output
balanced XLR and optional
FireWire connection (in
place of stereo input
channel)
Stereo master bus Bus, input channels,
group buses, stereo
returns or playback
Insert Jack, master output
balanced XLR and optional
FireWire connection (in
place of stereo input
channel)
Mono master bus Bus, input channels,
group buses, stereo
returns or sum of stereo
bus
Insert Jack and master
output balanced XLR
